Mo.Unit Blue for armature push button

The Motogadget Mo.Unit Blue allows you to mount dashboard buttons in place of the large original dashboards on your motorcycle.
In addition, the Mo. Unit offers many other possibilities (such as connecting your motorcycle to your smartphone via the Motogadget app). If you are only interested in replacing the original dashboards with the buttons, we recommend the D Box from our range (this is cheaper and easier to install / see similar articles in this description).

The connection and adjustment of the boxes is not easy. A good technical understanding should be available in any case, since we do not provide a plug & play solution with wiring diagram, etc..
Please have a look at the description of the Mo.Unit (you can find it below this description under the downloads).

We offer various buttons to choose from, which you can mount on the handlebar of your bike. Count on your bike how many buttons you need. Some buttons can be used twice (e.g. turn signal left can also mean turn signal off at the same time). If you press the button once, the motorcycle flashes, if you press it again, the turn signal is off again).
You can find the different buttons under the accessories in this description.

Other accessories such as the Mo.Button / cable sets etc. are on request of course also available from us.

Manufacturer specifications:

The new mo.unit blue has been further developed and significantly improved compared to the proven previous version. It now has 12 inputs and 10 outputs, interchangeable quality cable clamps and most importantly Bluetooth® LE. This allows the mo.unit blue to connect directly to our app 'mo.ride' on the smartphone. This functionality is unique in the motorcycle accessory sector.
The entire setup and the alarm system can be controlled via the mo.ride app. Fault diagnosis is also possible during operation and without removing the mo.unit. Likewise, a secure, encrypted keyless-go function can be used.
When activated, approaching the vehicle with one's own smartphone is sufficient to put the vehicle into start readiness. Thus, the on-board power can be switched on by pressing the start button. Pressing it again then starts the engine. Once switched on, the on-board power remains safely activated while driving, even without a phone.
The mo.unit blue is the digital control unit for a motorcycle, the heart of the entire vehicle electrical system. It can be operated with push-button fittings or with conventional, switching handlebar fittings. It switches all necessary components on the vehicle and at the same time it takes over the tasks of the electrical fuses.
Relays and individual components in the wiring harness are greatly reduced and a new, minimized wiring of the vehicle can be done in a very short time.
When using the mo.button, the number of all switch armature connections is reduced to a single cable.

Functions WITHOUT SmartPhone:

Complete digital push button control, 4-button or 5-button operation possible.
Complete replacement for the fuse box. 10 independent circuits are digitally monitored and switched off in case of malfunction. After elimination of the fault, the fuse function is automatically reset
Integrated, position-independent alarm system
Integrated, digital, load-independent flasher relay, automatic switch-off optional and adjustable, mo.wave mode selectable
Integrated hazard warning flasher system
Turn signal optionally adjustable as position light
Integrated parking light and headlight flasher
Control of low and high beam (up to 200 W switching power) with only one button
Integrated, digital brake light modulator, flashing mode programmable
Acceleration-controlled hazard brake light (automatic warning signal)
Integrated starter relay for starters with magnetic switch (up to 30 A switching capacity)
Intelligent and configurable control/switching off of the consumers in order to use the maximum starting energy of the battery during the starting process
Integrated digital horn relay
Two configurable auxiliary outputs AUX1 and AUX2
Diagnostic function for input assignment, output assignment, circuit switching status, short circuit diagnosis, etc.
Calibration and current measurement enables defect detection of all lamps
Functions WITH SmartPhone:

Encrypted connection via Bluetooth® LE (Low Energy), thus tamper-proof
extremely low power consumption of smartphone and mo.unit blue (with Bluetooth active 0.9mA and in powersave mode after 6 weeks of inactivity: 0.3mA)
Keyless-Go (readiness to start the vehicle by approaching it with your own smartphone)
Highly sensitive accelerometer allows to display your driving activity in mo.ride through an activity factor, number of turns, top speed, etc.
transmission of alarm events (with date, time, vehicle on the ground, etc.) to the app
Setting of mode and sensitivity of the alarm system
Monitoring of the current battery voltage in the app
Diagnosis of all inputs and outputs, measurement of currents, voltage, device temperature
Defect detection of all illuminants by calibration. Defective indicators cause doubling of the flashing frequency, status message in the app and audio notification by Rideassist.
Rideassist: optional turn signal sound and error messages in real time as audio output via helmet headset.
Manual switching of outputs via smartphone (except starter).
Firmware updates without removal at any location via smartphone and app.
Setup menu configuration without removal at any location via smartphone and app
Vehicle management with automatic notifications of maintenance tasks, condition of tires, chain, brake pads, oils, operating fluids, spark plugs, etc. by matching vehicle mileage via speedometer signal
Logbook records trips and stores all generated vehicle messages, alarm events and maintenance tasks
Display of parking position and Ping! to help with vehicle search
LIN bus connection available for later connection of suitable motogadget products
scope of delivery:

mo.unit blue
1 x M5 stainless steel screw
2 x M5 stainless steel screw with nut
1 x speedometer sensor with 2 magnets
Detailed mounting and operating instructions Translated with www.DeepL.com/Translator (free version)
